Guangzhou Shenzhen Factory Sale ABS Fiber Optical Terminal Box With SC/APC Connector Splitter
Product Description:
The Planar light-wave circuit (PLC) splitter is an optical power management device fabricated by using silica optical waveguide technology. It features a compact size, high reliability and wide operating wavelength range with good channel-to-channel uniformity. These PLC units are widely used in PON networks for optical signal power splitting.
Image:
Product Detail:
Brand: Tongmai/OEM/ODM
Model type: PLC Splitter
Connector: SC/APC
Wavelength: 1260-1650nm
Operating temperature: -40℃ to 85℃
Parameters: 1*2/4/8/16/32/64
Length: 1m or customer length
Characteristics:
● Good uniformity and low insertion loss
● Low polarization dependent loss
● Excellent environmental stability
● Excellent mechanical
● Compact design,suitable for installation in optical equipment
Application:
Optical Fiber Communication;
CATV;
Optical Transmission Backbone;
Optical Fiber Test and Measurement Systems;
Specification 1x2 1x4 1x8 1x16 1x32 1x64 1x128
Specifications:
| 1x N | ||||||||
|
|
|
Specification |
||||||
|
Parameter |
Unit |
|||||||
|
|
|
1x2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
|
|
Operate wavelength |
nm |
1260-1650 |
||||||
|
Insertion loss |
standar |
|
3.6 |
7 |
10.2 |
13.3 |
16.5 |
20 |
|
dB |
||||||||
|
|
MAX(p/s) |
|
3.8/4.0 |
7.2/7.4 |
10.5/10.7 |
13.5/13.9 |
16.5/17.2 |
20.0/21.5 |
|
PDL |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.3 |
≤0.3 |
|
|
Lossuniformaity |
dB |
≤0.6 |
≤0.8 |
≤1.0 |
≤1.4 |
≤1.6 |
≤1.9 |
|
|
Return loss@1550nm |
dB |
≥55 |
≥55 |
≥55 |
≥55 |
≥55 |
≥55 |
|
|
Wavelengthdependent |
dB |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
|
|
loss |
||||||||
|
Fiber length |
m |
1.2(±0.1) or customer specified |
||||||
|
Fiber length |
|
Corning SMF-28eor customer specified |
||||||
|
Fiber type |
dB |
≤0.5 |
||||||
|
Temperature stability(-40 |
dB |
≤0.5 |
||||||
|
to +85) |
||||||||
|
Operating/storage |
℃ |
-40 to +85 |
||||||
|
temperature |
||||||||
|
Max optical power |
mW |
300 |
||||||
